XSY-5.12kWh/10.24kWh/15.36kWh/20.48kWh 100Ah/200Ah/300Ah/400Ah 51.2V CB IEC62619 Power Brick Battery with WiFi and Bluetooth

Stackable Home Energy Storage System with WiFi & Bluetooth | Smart Lithium Battery for Solar Use
The Power Brick Battery (XSY Energy Storage System) is suitable for residential energy storage. One set provides electricity for the entire house. With high energy density and multiple mounting options, the stack rack battery is space-saving for all kinds of installations. To serve evolving load requirements, the modular design can fit your energy demand today and tomorrow.

Online inquiry

Previous Next

Detailed content Specification parameter Product packaging

Battery Specifications
Model No	XSY 5000U-5KWH
Nominal Parameters
Battery Chemistry	LiFePO4
Voltage	51.2V
Capacity	100Ah
Energy	5.12kWh
Operating Voltage	46–56V
Max. Charge Voltage	56Vdc
Max. Charge Current	100A (5120W)
Max. Discharge Current	100A (5120W)
Basic Parameters
Warranty Period [3]	10 years
Dimension (W/H/D)	590435165mm
Weight Approximate	50kgs
Master LED Indicator	4 LED (SOC:25%~100%)
Master LED Indicator	2 LED (working, alarming, protecting)
IP Rating of Enclosure	IP20 (Indoor use)
Storage Time/ Temperature	5months@25°C;3months@35°C;1month@45°C
Working Temperature	-20°C to 60°C @60+/-25% Relative Humidity
Storage Temperature	0°C to 45°C @60+/-25% Relative Humidity
Humidity	5%~95%
Altitude	≤3000m
Cycle Life (25±2°C,0.5C/0.5C,80%EOL)	≥6500
Certification	IEC62619, CE-EMC, UN38.3, MSDS
