Model No | XSY-R80K
| XSY-R100K | XSY-R120K | XSY-R133K |
Nominal Capacity | 81.92kWh | 102.4kWh | 122.88kWh | 133.12kWh |
Cell Matching | 128S1P | 160S1P
| 192S1P | 208S1P |
Working Voltage Range | 388-448V | 460-560V | 552-672 V | 598-728V |
Nominal Voltage | 409.6V | 512V
| 614.4V
| 665.6V
|
Weight | 969.6kg
| 1172kg | 1294.4kg | 1456.8kg
|
Dimension (WxDxH) | 1700*1200*1700mm
|
Battery Type | LFP(LiFePO4) |
Nominal Working Current | 100A |
Communication Port | CAN/TCP/IP |
Working Temperature Rang | Charge:0-55°C/Discharge:-20-55°C |
Waterproof | IP20 |
Installation Method | Floor-standing |
Cycle Life | 6500 |
Warranty Period | 10 years |
Peak Charge/Discharge Current (@25°C,5S) | 150A |
Discharge Rate of Module | ≤3.5%/month/@25°C |
Parallel Connection | 5 units in parallel |
C&I energy storage systems are larger and more robust compared to residential storage solutions, tailored to support the higher energy needs of commercial and industrial operations. XSY ENERGY provides a complete portfolio ranging from 80kWh, 100kWh, 120kWh, to 130kWh modular ESS, using advanced lithium-ion batteries for high energy density, long cycle life, and efficiency.
As a global leader in industrial battery supply, XSY ENERGY integrates inverters, battery racks, advanced BMS, fire protection, and intelligent cooling into one system, ensuring long-term safety and performance. These systems function as both commercial battery storage systems for daily energy optimization and commercial battery backup systems for critical power support during outages.
Key Benefits:
Flexible capacity options: 80kWh / 100kWh / 120kWh / 130kWh for different C&I needs
Trusted industrial battery manufacturers with proven global project experience
Industrial battery solutions integrating lithium-ion technology for efficiency and reliability
Provides commercial battery energy storage systems for factories, business centers, and industrial parks
Functions as both commercial battery storage systems and commercial battery backup systems
Compatible with solar PV and hybrid microgrids for maximum energy utilization
By choosing XSY ENERGY, businesses partner with one of the leading industrial battery manufacturers, ensuring access to reliable industrial battery supply and scalable commercial battery energy storage systems tailored to diverse applications.
